| Chassis configuration |
| wheelbase | 5000mm |
| engine | CA4DK1-22E6 |
| gearbox | 8 gear |
| Driving mode | 4x2 |
| Tyre specification | 10.00R20 |
| Number of tires | 6 |
| Top configuration |
| Flat bed size | 7300*2450mm |
| Flat bed configuration | 10 tons of top, 10 tons of hoist, 6 mm thick pattern plate, imported hydraulic parts, 10 tons of three-section rear bracket arm, flat plate sinking, the total length of the board is 8 meters (mainboard 7.3 meters, 1.2 meters of hydraulic turnover tail plate), one set of support sockets, two pairs of tow forks, one set of tire holding device, binding land strip, auxiliary car, two auxiliary gas pipes, alarm lights |
Jiefang J6L wrecker truck has a variety of models, the following is the introduction of some common models:
1. One tow two wrecker truck
•
Tow Truck Chassis configuration: New J6L full floating flat top half cab with LCD instrument, electric glass lift,
manual rearview mirror, etc. The driver's seat is an air-damping seat, with automatic air conditioning and other configurations.
The chassis is equipped with Dachai CA6DH1-24E65 engine, matching CA8TAX100F transmission,
and the rear axle is the Phi 435 weld bridge.
• Wrecking Truck Top configuration: Top is 10 tons, equipped with 10 tons of lifting, 6 mm thick pattern plate,
imported hydraulic parts, 10 tons of three-section rear bracket arm. Plate to do sinking, tail with hydraulic turnover tail plate,
also equipped with a pair of socket, tow fork two pairs, holding a set of tire device, binding land strip,
auxiliary car, hand washing water tank, double chain hook.
• Chassis configuration: New J6L full floating flat top half cab, leather ventilated heated seats,
large diesel 260 HP engine model CA6DK1-26E6, with free 9-speed transmission CA9TAX100M.
• Top configuration: slab length up to 9.9 meters, rear bracket 15 tons, 10 tons hydraulic winch.
The 6mm pattern plate is used, the plate is sunk, and the frame can be customized.
The top adopts imported multi-way valve, equipped with high and low three sets of fork, etc.
• Chassis configuration: The wheelbase is 5.8m plus 1.35m,
equipped with the latest Daishadoitz Sino-French 320 HP six-cylinder engine,
matched with the Fast 10-speed transmission, and the tire size is 1200R22.5 vacuum tires.
• Top configuration: 18 tons flat plate and rear tow arm, the flat plate is 8 thick thickened carbon steel pattern plate,
the plate is equipped with 15 tons winch, with 45 meters steel wire rope,
the edge of the plate is attached to 16 thick steel plate for sinking design.
Wrecker truck functions:
1. Traction of vehicles with road faults
• Vehicles that have broken down and cannot operate normally, such as cars, SUVs, light trucks, etc.,
can be towed to a safe repair location. Its traction methods are various, the common towing type,
by connecting the front or rear axle of the faulty vehicle, using the power of the wrecker itself to tow away the faulty vehicle.
2. Accident vehicle towing
• At the scene of a traffic accident, wreckers are able to clear the vehicle and keep the road clear.
For severely damaged vehicles after a collision, such as body deformation, wheel damage, etc.,
the wrecker can rely on strong towing and carrying capacity to remove the accident vehicle from the accident scene.
3. Faulty vehicle transport
• Some wreckers are equipped with flatbed devices, which can load the faulty vehicles directly onto the
flatbed for transport like a "mobile flatbed". For example, this method is effective for vehicles with damaged chassis,
falling tires, or vehicles that cannot be moved by traction.
4. Vehicle righting and lifting
• Some high-end wreckers are equipped with lifting equipment, so that when the vehicle rolls over or falls into a ditch, etc.,
the vehicle can be righted and lifted, and then placed in a safe position for subsequent towing or carrying.
