Home > Products > Special Purpose Vehicle > Synchronous Gravel Sealing Truck > DONGFENG 15CBM synchronous gravel sealing truck





View the big picture

DONGFENG 15CBM synchronous gravel sealing truck

Name: DONGFENG 15CBM synchronous gravel sealing truck
Brand: Cheng Li Automobile Group
Price: 88500 USD
Rating: 4.8 (6 reviews)

Unit Price:

USD 88500 - 89500 / Piece/Pieces

Payment Type:

L/C,T/T

Incoterm:

FOB,CIF,EXW

Contact Now

Add to Basket
Share to:

Basic Info

Brand: clw

Old And New: New

Gearbox Type: Manual

Emission Standards: Euro 3, Euro 5

Fuel: Diesel

Place Of Origin: China

Vehicle Size: 8860*2500*3530mm

Tank Volume: 15cbm

Total Mass: 18000kg

Curb Weigh: 11380kg

Seating: 3

Wheelbase: 5300mm

Number Of Tires: 6

Tyre Size: 10.00R20

Horse-powe: 230HP

Brake System: Air brake

Additional Info

Productivity: 30unit/month

Transportation: Ocean,Land

Place of Origin: china

Supply Ability: 30unit/month

Certificate: 3c

Port: tianjin,shanghai,qingdao

Payment Type: L/C,T/T

Incoterm: FOB,CIF,EXW

Product Description

DONGFENG 15CBM Synchronous Gravel Sealing Truck Parameter Settings

1. Introduction to the use of synchronous gravel seal truck

Synchronous gravel sealing vehicle is used for road surface, bridge floor waterproofing, and gravel sealing process in the lower sealing layer.

Special equipment that synchronizes the spraying of the asphalt binder and the spreading of the aggregate

so that there is the fullest surface contact between the asphalt binder and the aggregate to achieve the maximum bond between them.

CLW5180TFCC6 synchronous crushed stone is a synchronous crushed stone sealing machine developed and designed by

our company with independent intellectual property rights, which is improved on the basis of the same type of synchronous crushed stone,

so that it can be constructed in harsher conditions and enhance the stability of equipment operation. It has reached the integration of machine,

electricity and hydraulic operation, the equipment operation process has been simplified, the operation is simple,

and the technology of the whole machine has reached the world advanced level.

2. Performance parameters of highway maintenance vehicle

◆ Product model: CLW5180TFCC6

◆ Quality: 10600kg

◆ Overall size: 9000×2500×3530(mm)

◆ Leaching pot: 6m³

◆ Stone warehouse: 8m³

◆ Spreading width: 3750mm

◆ Nozzle spacing: 125mm

◆ Asphalt spreading capacity: 0.2 ~ 3.5L/m2

◆ Heating method: Riya Road diesel burner + thermal oil automatic heating

◆ Spraying medium: hot asphalt, SBS modified asphalt, emulsified asphalt, modified emulsion asphalt.

◆ Spreading error: ±2%

3. The parameters of main accessories are shown in the following table:

Serial number	name	Model and specification	Owning system	remark
1	automotive chassis	DF	chassis	DONGFENG
2	engine	YC6A260-33		Yuchai 260 HP (Euro 3)
3	wheelbase	5300mm
4	Asphalt tank capacity	6cbm		Inner tank volume
4	Stone bin	8cbm		V-hopper (gravity flow)
5	Thickness of insulation layer	50mm		Rock wool insulation
6	Outer stainless steel	1.2m		1.2 thick stainless steel plates
7	Power stripper	For sealing cars	Source of working power
8	Double gear pump	05-130-BD31	Hydraulic system	Made in Tianjin
9	Proportional valve	EFRD-G03-160-5-31		Made in Taiwan
10	Asphalt pump motor	05-130-BD31		Made in Tianjin

4. Synchronous gravel sealing truck advantages

◆ Exclusive use of full hydraulic drive mode, no need to add any auxiliary power to make the operation more simple and convenient;

◆ Exclusive use of efficient heat conduction oil boiler heating, so that the temperature rise rate is greatly improved,

breaking the traditional flue heating method;

◆ The equipment adopts V-shaped hopper, without lifting the hopper to rely on gravity flow alone can realize the stone debris distribution work,

more convenient culvert construction, bridge construction, and bend construction;

◆ The equipment is completely electrically controlled, with a high degree of automation, and can accurately calculate the amount of asphalt spraying

and stone chip spreading during the construction of the equipment;

◆ The feed door is controlled by Angle meter to ensure the accuracy of the equipment;

◆ Reduce the labor intensity of construction, save human resources, reduce construction costs, improve work efficiency and work quality;

◆ Stable operation of the whole machine, uniform spreading, can freely adjust the width of asphalt spreading;

◆ Good insulation layer to ensure insulation performance index ≤20℃/8h, and anticorrosive durable;

◆ Can spray a variety of asphalt media, spread from S3 to S24mm stone;

◆ The equipment adopts nozzles with high processing accuracy, so that the spraying consistency and spraying effect of each nozzle are fully guaranteed;

◆ The overall operation is more humane, with remote control, but also on-site operation, which brings great convenience to the operator;

◆ Through the perfect combination of electrical control and constant pressure device of hydraulic system, zero-start spraying is realized;

◆ The whole machine has undergone many engineering construction improvements, reliable performance,

easy operation and maintenance, and high cost performance.

Product Categories : Special Purpose Vehicle > Synchronous Gravel Sealing Truck
