Home > Products > Special Purpose Vehicle > Bulk Feed Truck > FAW Bulk Feed Tank Truck





View the big picture

FAW Bulk Feed Tank Truck

Name: FAW Bulk Feed Tank Truck
Brand: Cheng Li Automobile Group
Price: 61000 USD
Rating: 4.5 (32 reviews)

Unit Price:

USD 61000 - 61500 / Piece/Pieces

Payment Type:

L/C,T/T

Incoterm:

FOB,CIF,EXW

Contact Now

Add to Basket
Share to:

Basic Info

Brand: clw

Old And New: New

Gearbox Type: Manual

Emission Standards: Euro 3, Euro 5

Fuel: Diesel

Place Of Origin: China

Vehicle Size: 11000*2550*3950mm

Box Volume: 40cbm

Total Mass: 31000kg

Curb Weight: 13100kg

Seating: 3

Wheelbase: 1900+4500+1350mm

Number Of Tires: 10

Tyre Size: 11.00R20

Horse-powe: 292HP

Brake System: Air brake

Additional Info

Productivity: 30unit/month

Transportation: Ocean,Land

Place of Origin: china

Supply Ability: 30unit/month

Certificate: 3c

Port: tianjin,shanghai,qingdao

Payment Type: L/C,T/T

Incoterm: FOB,CIF,EXW

Product Description

FAW Bulk Feed Tank Truck Parameter Settings

Name of vehicle	Liberation 8x4 Bulk Feed Truck	CLW5312ZSLC5	CLW5312ZSLC5
Vehicle size	12000×2500×3995	Standard volume of material tank	40m³
Load weight	20-21 tons	Total mass	31000Kg
Rated quality	15280Kg	Quality of equipment	15590Kg
Hydraulic system winch	Imported hydraulic components	Electric system winch	Domestic parts/imported parts optional
Number of feed silo	4	Material of tank body	3mm manganese steel plate
Discharge time	32 minutes	Discharge speed	≥500kg/min
Discharge residue rate	≤1％	Maximum elevation of gargoyles	60°
Horizontal maximum transfer distance	7.2 metres	Maximum vertical feed height	9 metres
Discharge rotation angle	360 degrees (180 degrees on one side)
Electric winch can be selected according to the actual situation of the user (three-phase electric supporting places), for no three-phase electric places, the electric system winch can also choose the vehicle three-phase generator or choose the hydraulic winch. The whole vehicle has 3 stranding dragons, driven by 3 5.5KW motors, the top stranding dragon is lifted by hydraulic control, and the electric control part of the stranding dragon can choose domestic parts or imported parts, and the unloading can be operated by wireless remote control. Hydraulic system stranding, all hydraulic system components, hydraulic pump, hydraulic motor, hydraulic valve, high pressure explosion-proof pipe are imported parts, hydraulic pump for vane pump, uniform flow, smooth operation, low noise, higher efficiency than gear pump, more durable.

FAW 40 cbm bulk feed truck has Jiefang J6 and Jiefang JH6 and other models, the following is your detailed introduction:

1. Faw Jiefang J6 feed truck • Chassis configuration: Jiefang J6 rear eight series chassis, equipped with Dazai 325 horsepower engine,

FAW 10-speed transmission, wheelbase of 1950+4550+1350mm, 11.00R20 steel tire, automatic air conditioning,

front and bottom protection device. • Top configuration: Effective volume of 40 cubic meters, can load 20 to 28 tons of feed, standard with 4 silos,

tank body made of 4mm high-quality carbon steel plate. The vehicle has 3 winch dragons, driven by 3 5.5KW motors,

the top winch hydraulic control lifting, can be rotated around 180°, the tank body can be multiple independent silos,

can independently control the unloading sequence and speed of each silo, discharge tube tilt 60 degrees, vertical unloading height 8.6 meters.

2. Faw Jiefang JH6 feed truck

• Chassis configuration: high-top two-bedroom cab, 1900+4500+1350 wheelbase, four-point air suspension.

• Top configuration: The tank is made of manganese steel, with a volume of 40 cubic meters and a fully hydraulic rotary winch.

Equipped with CA6DM2-46E6 six-cylinder 11-liter 460 horsepower engine, maximum torque 2300N.m. Equipped with hydraulic

operation unit, fast discharge speed, low crushing rate, and large main channel radiator and 600L aluminum oil tank,

FAW aluminum 12-speed transmission.

3. Feed truck tank configuration

Effective volume of 40 cubic meters, can hold 20 to 28 tons of feed, standard with 4 silos, tank material is made of 4mm high-quality carbon steel plate,

the whole vehicle 3 skein, driven by 3 5.5KW motors, the top skein hydraulic control lifting, can be rotated around 180°,

the tank can be according to user requirements to do multiple independent silos, can independently control the unloading sequence

and speed of each silo. Discharge tube tilt 60 degrees, vertical discharge height 8.6 meters.

4. Feed tank truck features

• Efficient transportation: large tonnage feed can be transported in the effective time, the unloading speed is fast,

and the unloading time of the whole vehicle is about 20 minutes.Cost savings: Transporting feed in bulk saves labor and costs and reduces

feed losses compared to shipping in bags.

• Environmental hygiene: bulk feed is sealed in the tank to avoid contamination and ensure feed quality.

• Flexible operation: standardized parts, easy maintenance, and can be customized according to user needs, suitable for a variety of farming enterprises.

Product Categories : Special Purpose Vehicle > Bulk Feed Truck
