Home > Products > Special Purpose Vehicle > LED Advertising Truck/Stage Truck > Foton small LED advertising truck





View the big picture

Foton small LED advertising truck

Name: Foton small LED advertising truck
Brand: Cheng Li Automobile Group
Price: 15000 USD
Rating: 4.7 (32 reviews)

Unit Price:

USD 15000 - 15500 / Piece/Pieces

Payment Type:

L/C,T/T

Incoterm:

FOB,CIF,EXW

Contact Now

Add to Basket
Share to:

Basic Info

Brand: clw

Old And New: New

Gearbox Type: Manual

Emission Standards: Euro 5, Euro 3

Fuel: Gasoline

Place Of Origin: China

Vehicle Size: 5100*1780*2650mm

Gross Mass: 2245kg

Curb Weight: 2115kg

Seating: 2

Wheelbase: 3070mm

Number Of Tires: 4

Tyre Size: 175R14LT

Horse-powe: 115HP

Brake System: Disc brake

Additional Info

Productivity: 30unit/month

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 30unit/month

Certificate: 3c

Port: tianjin,shanghai,qingdao

Payment Type: L/C,T/T

Incoterm: FOB,CIF,EXW

Product Description

Foton small LED advertising truck introduction

Basic configuration of LED advertising truck

Serial number	Name	Parameter	Notes
1	chassis	bj	Euro 6 emission standards(Optional)
2	Engine type	DAM15KR	Gasoline engine
3	Displacement/horsepower	1.498/85
4	Vehicle size of publicity vehicle(mm)	5100x1780x2650	External dimensions
5	Box body material outside the metal plate inside the decorative plate	Sheet metal thickness 1.4 mm	Composite steel frame box frame, the middle filled with polyurethane extrusion plate
6	Vehicle specifications	One side of the cab LED full-color screen, one side of the glass roller, the front single red bar screen, the rear single red screen

Foton small advertising trucks mainly have the following models and characteristics:

1. Foton Xiangling mobile led truck

• Appearance and size: The overall design is rounded and smart, and the design style is sedan.

The body size is 5250x1800x2750mm, wheelbase 2850mm.

• Chassis configuration: Dongan 115hp engine, displacement 1.5L, tires 175r14, equipped with power steering,

hydraulic clutch, electric doors and Windows, central control lock, rear wheel adopts twin design, strong bearing capacity and stability.

• led billboard truck top configuration: p6, p5, p4 and other outdoor color screens are optional on the front driving side,

and p10 single-red subtitle screen is standard on the front eyebrow and rear door; The passenger side is a roller advertising light box;

Equipped with Chongqing Wing Tiger gasoline generator, single side 6.5kw, double side 8kw;

There are industrial computer, power amplifier, sound column and other equipment.

2. Foton led advertising vehicle and display truck

• Appearance and dimensions: Length 5.1 meters, width 1.71 meters, height 2.64 meters. The vehicle is beautiful in shape and rich in color.

• Chassis configuration: Six emissions, Dongan 115 HP gasoline engine, 1.5L displacement, wheelbase 3070mm,

equipped with ABS, five-speed transmission, manual doors and Windows, etc.

• Top configuration: the driving side is an outdoor color screen, which can be lifted or hydraulically lifted;

The passenger side is a glass roller advertising light box, which can automatically play the advertising light sheet.

Equipped with Escape gasoline generator, single side 6.5kw, double side 8kw, as well as industrial control computer, power amplifier, sound column, etc.

3. Foton Xiangling V1 double row LED advertising truck

• Appearance and dimensions: Length 5.4 m, width 1.75 m /1.85 m, height 2.65 m.

• Chassis configuration: Dong 'an 115hp, 1.5L displacement, ABS, single wheel, power assisted, no air conditioning,

manual doors and Windows.

• Top configuration: the same as Futian Xiangling V1 single row.

4. Advertising vehicle equipment maintenance

• Display maintenance: If it is an LED display, clean the dust on the surface of the screen regularly.

Wipe gently with a soft, dry cloth to avoid scratching the screen. Also check whether the cable interface of the display screen is loose, if it is loose, plug it in time.

• Generator maintenance: For on-board generators, maintenance should be carried out according to the use time.

Replace the oil and oil filter after 100-150 hours of operation; After 200-300 hours of operation, clean the air filter, etc.

And check the output voltage and frequency of the generator regularly.

• Lighting system inspection: Regularly check whether the advertising light box and the vehicle's lighting fixtures are working properly.

If the bulb is damaged, replace the bulb of the same model in time.
