Cheng Li Automobile Group
| Unit Price: | USD 52000 - 53000 / Piece/Pieces |
|---|---|
| Payment Type: | L/C,T/T,Paypal |
| Incoterm: | FOB,CIF,EXW |
Basic Info
Brand: clw
Old And New: New
Gearbox Type: Manual
Emission Standards: Euro 3, Euro 5
Fuel: Diesel
Place Of Origin: China
Vehicle Size: 8560*2500*3350mm
Tank Volume: 10cbm
Gross Mass: 18000kg
Curb Weight: 9650kg
Seating: 3
Wheelbase: 4500mm
Number Of Tires: 6
Tyre Size: 10.00R20 18RPR
Horse-power: 220HP
Brake System: Air brake
Additional Info
Productivity: 30unit/month
Transportation: Ocean,Land
Place of Origin: china
Supply Ability: 30unit/month
Certificate: 3c
Port: tianjin,shanghai,qingdao
Payment Type: L/C,T/T,Paypal
Incoterm: FOB,CIF,EXW
Product Description
| Serial number | name | Model and specification | Owning system | Remarks
|
| 1 | Truck chassis | SX | chassis | Shaanxi Automobile Delong F3000 |
| 2 | engine | Wp4.6NQ220E61 | Weichai 220HP | |
| 3 | wheelbase | 4500mm |
| |
| 4 | Asphalt tank capacity | 10 cubic meters |
| Inner tank volume |
| 5 | Thickness of insulation layer | 50mm | Rock wool insulation | |
| 6 | Outer stainless steel | 1.2mm | 1.2mm stainless steel plate | |
| 7 | Power stripper | For sealing cars | Source of working power |
|
| 8 | Double gear pump | 05-130-BD31 | Hydraulic system | Made in Tianjin |
| 9 | 比例阀 | EFRD-G03-160-5-31 | Made in Taiwan | |
| 10 | Asphalt pump motor | 05-130-BD31 | Made in Tianjin | |
| 11 | Asphalt pump | QGB950 | Asphalt spraying system | Shang Quoi， 950L/min |
| 12 | Nozzle number | 30 | Control mode: 1 control 1 | |
| 13 | burner | G20 (200,000 kcal/hour) | Heating system | Riello |
| 14 | Heat-conducting oil pump | RY25-25-160 | Hebei (Province) | |
| 15 | Control system mode | Cab touch screen computer control + Parking control box operation (standby) | Control system | Control system adopts: Siemens modular design, running faster and more smooth, low failure rate |
| 16 | Speed sensor | Ni5-G12 | Turk, Germany | |
| 17 | Temperature controller | WZP-230 | Shanghai Xinghui |
Product Categories : Special Purpose Vehicle > Asphalt Distribution Truck
