Home > Products > Garbage Truck > Compactor Garbage Truck > Cheng Li 50cbm compressed garbage trailer





View the big picture

Cheng Li 50cbm compressed garbage trailer

Name: Cheng Li 50cbm compressed garbage trailer
Brand: Cheng Li Automobile Group
Price: 65500 USD
Rating: 4.7 (33 reviews)

Unit Price:

USD 65500 - 66300 / Piece/Pieces

Payment Type:

L/C,T/T

Incoterm:

FOB,CIF,EXW

Contact Now

Add to Basket
Share to:

Basic Info

Brand: clw

Old And New: New

Gearbox Type: Manual

Emission Standards: Euro 3, Euro 5, Euro 2

Fuel: Diesel

Place Of Origin: China

Vehicle Size: 13610*2550*3998mm

Gross Mass: 40000

Curb Weight: 19500

Wheelbase: 6090+1310+1310mm

Number Of Tires: 12

Tyre Size: 12R22.5 18PR

Brake System: Air brake

Additional Info

Productivity: 30unit/month

Transportation: Ocean,Land

Place of Origin: china

Supply Ability: 30unit/month

Certificate: 3c certification

Port: tianjin,shanghai,qingdao

Payment Type: L/C,T/T

Incoterm: FOB,CIF,EXW

Product Description

Cheng Li 50cbm compressed garbage Trailer Parameter Settings

compactor garbage trailer parameter configuration
Chassis section
Complete vehicle model	Cl9400ZYSAQC
Chassis type	CL
Vehicle size	1361025503998mm
total mass	40000kg
Load mass	20500kg
curb weight	19500kg
wheelbase	6090+1310+1310mm
Rear track	1840/1840/1840
Number of tires	12
tyre size	12R22.5 18PR
Number of axes	3
Top part
Box volume	50cbm
Filling cycle time	≤25s
Turnover cycle time	≤10s
Type of tilting mechanism	2 240L plastic buckets (standard) 660L turning mechanism (standard) Semi-sealed bucket (optional)

Chengli 50cbm Compacting garbage trailer Features:

1. Compress the basic parameters of Compactor Garbage Truck

• Volume and load: the box volume of 50 square, can load more than 35 tons of domestic waste,

and even some users can compress more than 38 tons of waste, the total mass of 40 tons.

• Dimensions: length 13.61 meters, width 2.55 meters, height 3.998 meters

2. Structural design of Garbage Truck

• Box: The use of steel plate welded into a solid frame structure, good force, no deformation,

effectively ensure the garbage bearing and transportation safety.

• Tail: The spoon type turning mechanism is used, which can compress 5-7 square of domestic garbage at a time,

which is convenient for garbage collection and pouring.

3. garbage compactor truck power system • Chassis force extraction: Through chassis force extraction, the vehicle engine power can be used to drive the hydraulic system

to complete garbage compression and other operations.

• Motor force extraction: The box is equipped with a 90KW 380V motor, and the motor force extraction mode can be optional

to meet the needs of different working scenarios.

4. Compress the hydraulic system of garbage truck

• Component configuration: Hydraulic pump adopts Hefei Wanyi 80/60, 150-liter flow dual pump, oil cylinder external,

slide cylinder and scraper cylinder 160/80, are modulated, powerful.

• Cooling system: equipped with 300 liter hydraulic radiator and 600 liter oil pressure tank,

it can work continuously for 10 hours to ensure normal oil temperature and ensure stable operation of the hydraulic system.

5. Compress the garbage truck control system

• Intelligent control: CAN intelligent screen with voice prompt, fault detection prompt and remote control function

to achieve intelligent operation and management.

• Operation mode: With flashlight integrated operation mode, both inside and outside the cab can be operated,

and each mechanism has automatic and manual operation modes, which is convenient for debugging, maintenance and fault handling.

6. Environmental performance

The whole vehicle is fully sealed, and the sewage in the compression process directly enters the sewage compartment

to avoid secondary pollution caused by sewage leakage during transportation.
