| Vehicle parameter configuration |
| Vehicle brand/vehicle name | Clw | Wrecker truck |
| Engine brand | weichai Power | Horsepower | 400 horsepower |
| Type of fuel | Diesel fuel | Displacement and power (ml/kw) | 12400 | 294 |
| Vehicle size | 11575*2550*3480mm | Number of tyres | 12
|
| Number of axes | 4 | Form of steering | The steering wheel |
| Total mass (kg) | 31000 | Quality of equipment(kg) | 25300 |
| Number of persons allowed to ride in the cab (person) | 3 | Maximum design speed (km/h) | 90 |
Description of SinotruK HOWo 8x4 Wrecker Tow Truck: 1. Sinotruk Howo chassis configuration
• Cab: HOWo classic cab, spacious space, some models for the ultra-wide cab, good comfort, such as HOWo H77L cab.
• Engine: Powerful, can be equipped with German MC11.40-60 engine, 400 horsepower, meet the national six emission standards,
output torque, superior power performance, can adapt to complex road conditions and rescue scenes.
• Transmission: equipped with 10 or 12 gear transmission, smooth shift, high transmission efficiency,
can meet the needs of different working conditions. • Axle and girder: The use of high-strength axle and girder,
such as Man 16 tons double reduction bridge,
strong bearing capacity, can ensure the stability and safety of the vehicle when towing heavy objects.
• Tire: Generally choose 12.00 steel wire tire, good wear resistance, strong grip, can adapt to various road conditions.
2. Heavy wrecker truck installation configuration • Boom: Usually equipped with two-section hexagonal boom or 40-ton 3-section hexagonal telescopic boom,
360° full hydraulic rotation, flexible boom, lifting range, lifting weight up to 20-50 tons.
• Winch: Equipped with 2 hydraulic winches, the pulling force ranges from 100KN-150KN, the length of the wire rope is 50-55m,
which can realize the functions of pulling and righting the faulty vehicle.
• Bracket arm: mostly three-section bracket arm or 40-ton three-section rear bracket arm, split structure, strong lifting ability,
can pull heavy faulty vehicles, part of the bracket on both sides of the reinforcement plate, improve the strength and stability of the bracket arm.
• Operating device: Standard double-sided linkage operating device, can also be equipped with remote control operation,
easy and flexible operation, can accurately control the clearing and lifting action.
3. Functional characteristics of heavy wrecker tow truck • Strong rescue capability: It can tow and lift large faulty vehicles, rescue all motor vehicles, and can also be used for lifting
and traction operations, suitable for a variety of rescue scenarios such as highways.
• Safe and reliable: equipped with large warning light alarm and rescue auxiliary lighting function,
to ensure the safety of personnel and operation standards during the clearance operation, the body structure is strong,
the performance of each component is stable, and can work stably in complex environments.
• Humanized design: ultra-wide cab provides comfortable operating space, some models cab with front counterweight,
improve vehicle driving stability, split compartment is easy to store and maintain equipment.
