| Vehicle parameter configuration |
| Vehicle brand/vehicle name | Clw | Wrecker truck |
| Engine brand | weichai Power | Horsepower | 550 horsepower |
| Type of fuel | Diesel fuel | Displacement and power (ml/kw) | 12540 | 405 |
| Vehicle size | 11700*2550*3450mm | Number of tyres | 14 |
| Tire specifications | 12.00R20 |
| Number of axes | 5 | Form of steering | The steering wheel |
| Total mass (kg) | 53000 | Quality of equipment(kg) | 27800 |
SHACMAN 53 tons of debris removal rescue vehicle introduction:
1.SHACMAN heavy duty truck chassis configuration
• Cab: Delong X5000 cab with luxurious and comfortable interior configuration and spacious space.
• Engine: Equipped with Weichai WP13 engine, displacement 12.54L, horsepower up to 550, strong power,
can meet the heavy duty obstacle clearance needs.
• Transmission: Equipped with FASTster 12-speed transmission, smooth shift, high transmission efficiency,
can adapt to various complex working conditions.
• Axle: five-bridge design, the third bridge is a lifting bridge, with Hande axle, strong carrying capacity,
to ensure the stability and safety of the vehicle when towing heavy objects.
• Tire: The selection of large specifications of steel wire tire, good wear resistance, strong grip, can adapt to various road conditions.
2.50 ton wrecker truck mounted configuration • Lifting arm: Equipped with two hexagonal lifting arms, the maximum lifting weight can reach 50 tons,
the lifting arm is flexible, and the lifting range is large.
• Hoist: Install two 20 tons of hoist, wire rope length of 45 meters, strong pulling force,
can achieve the function of pulling and righting the faulty vehicle.
• Bracket arm: Adopts 50 tons three-section rear bracket arm, split structure, strong lifting ability, can pull heavy faulty vehicles.
• Oil cylinder: The selection of naval force oil cylinder, reliable quality, stable performance, can ensure the normal operation of the equipment.
• Control system: equipped with remote remote control, can realize the remote control of the wrecker, easy and flexible operation,
improve work efficiency and safety.
• Strong rescue capability: capable of towing large faulty vehicles, suitable for various rescue scenarios such as highways and urban roads,
which can quickly and effectively remove road obstacles and ensure smooth roads.
• Safe and reliable: the interior of the cab is fully equipped to provide a good working environment for the operator;
The vehicle is equipped with perfect safety devices, such as warning lights, alarms, etc., to ensure the safety of personnel
and operation standards during the clearance operation.
• Advanced manufacturing process: The electrophoretic paint process can effectively improve the anti-corrosion performance
and appearance quality of the vehicle, and extend the service life of the vehicle.
4.After-sales guarantee for Chengli special vehicles: • Lifetime warranty: For products that exceed the warranty period, replacement parts will only be charged the relevant cost.
• Free training: After the purchase of the car, the factory arranges engineers to guide the operator on the spot,
learn the theory and practical operation, so that they can master the basic theory, performance and function of the special vehicle,
and can skillfully operate and carry out daily maintenance and eliminate general technical faults.
